Material:
Case Zing-galvanized steel S355, powder painting
Case RAL 7012
Rollers fastening RAL 1021
Saddle RAL 5010
Can be produce of stainless or acid-resistent steel
Rollers Special polyamide
Can be produce with add rollers
Bearing Spherical ball bearing
Rollers axis Steel bushings, galvanized
Bolt joint Metric system
Seals Rubber EPDM
End cap PVC
Saddle Zing-gilvanized steel
Holdfast Rubber EPDM
Technical specifications:
Maximum load 180 kg
Maximum travel speed 120 m/min
Operating temperature Standart -30oC and above. By order -40oC and above or -50oC and above. Other desings.
Minimum beam dimension 140
Please, notice,
RM International Group Sp. z o.o. reserves the right to introduce modifications into desing of any element.
