Material:
Case Zing-galvanized steel S355, powder painting
Case RAL 7012
Rollers fastening RAL 1021
Saddle RAL 5010
Can be produce of stainless or acid-resistent steel
Rollers Hurdened galvanized steel
Bearing Spherical ball bearing
Roller axis Steel bushings, galvanized
Bolt joint Metric system
Seals Rubber EPDM
End cap PVC
Saddle Zing-galvanized steel
Holdfast Rubber EPDM
Technical specifications:
Maximum load 50 kg
Maximum travel speed 100 m/min
Operating temperature Standart -30oC and above. By order -40oC and above or -50oC and above. Other disings.
Minimum beam dimension 100
Please, notice,
RM International Group Sp. z o.o. reserves the right to introduce modifications into desing of any element.
