Material:
Case Zing-galvanized steel S355, powder painting
Case RAL 7012
Rollers fastening RAL 1021
Saddle RAL 5010
Can be produce of stainless or acid -resistent steel
Rollers Hurdened galvanized steel
Can be produce with add rollers
Bearing Spherical ball bearing
Roller axis Steel bushings, galvanized
Bolt joint Metric system
Seals Rubber EPDM
End cap PVC
Saddle Zing-galvanized steel
Holdfast Rubber EPDM
Technical specifications:
Maximum load 150 kg
Maximum travel speed 120 m/min
Operating temperature Standart -30oC and above. By order -40oC and above or -50oC and above. Other disings.
Minimum beam dimension 120
Please, notice,
RM International Group Sp. z o.o. reserves the right to introduce modifications into desing of any element.
